Products Vita Hardware products

FEATURES & BENEFITS

• Tested in accordance to BBA
• Six suited finishes
• High profile to give greater knuckle clearance during operation
• Left and right hand variant available, with positive stop location
• Push-to-open locking mechanism
• Green button available for fire egress application
• Colour co-ordinated screw covers
• Profile-specific spindle lengths
• Packaged as 10 per box, 6 boxes per carton

OFFSET WINDOW
HANDLE HB 118

The Claymore offset window handle is engineered to work with all standard espagnolette and shootbolt mechanisms with 43mm centres. Suitable for PVC-u, Aluminium and Timber window profiles, this range offers outstanding performance and reliability.
Aimed at the prestigious end of the market, the Claymore offset handle is produced to meet the demands associated with the newbuild and commercial sectors, while still retaining the aesthetics and contemporary design that appeals to the domestic and trade fabricator.

CLAYMORE

HB118 window handle drawing

Available Colors
	White
	Black
	Polished Gold
	Polished Chrome
	Smoked Chrome
	Satin Silver

Color	Coating Type	BS EN 1670 : 2007
White	Powder Coat	Grade 5 (480 hours)
Black	Powder Coat	Grade 5 (480 hours)
Polished Gold	Electrophoretic Lacquer	Grade 4 (240 hours)
Polished Chrome	Electro-Plating	Grade 4 (240 hours)
Smoked Chrome	Electro-Plating	Grade 4 (240 hours)
Satin Silver	Electro-Plating	Grade 4 (240 hours)
